Our first on-site tour for day 2 was to
The Botanical Research Institute of Texas (BRIT). The BRIT is a scientific research center and education endeavor that takes botanical specimens and attempts to understand the interaction between people and plants. The Institute performs research throughout state of Texas and Internationally in areas such as the Amazon. The sustainability project currently under way,
Andes to Amazon is "an international, multidisciplinary team of scientists, students, and local residents dedicated to studying organisms and their interactions with the environment" that focuses on work in the Andes-Amazon region of southeastern Peru. The focus is on how can we can allow people to live in the Amazon without destroying it.
The original BRIT was founded in 1987. Around 2002, Southern Methodist University (
SMU) had a dried plant collection (aka, "
Herbarium") of 350,000 plants. When the college fell on hard times they looked for a place to relocate their collection. With the help of multiple benefactors the BRIT was able to take on SMU's collection and set up a headquarters on the east side of Fort Worth, TX in an old abandoned plant. In 2010, they had amassed such a large collection (over 1 million specimens) they realized a new building would have to be obtained. Since the BRIT is a research institute devoted to the education of sustainability, they knew a sustainable building was the only logical course of action. The BRIT wanted a benchmark on which they could construct a truly sustainable building and decided the new headquarters would have to be certified LEED platinum. In July 2011 they received their certification.
Instead of building from the ground up, the founders were able to purchase another building. They worked with the city to purchase the Public Health Center off of University St in near the Botanic Gardens. The BRIT was able to re-purpose 97.6% of the materials from the original building and in the remaining lot behind the building they have set up a native prairie established by Dr. Tony Burgess (lead ecologist on the Biosphere in Arizona).
The re-purposed building took only 11 months to construct and is separated into two separate wings; a library and offices/education. The lighting for the BRIT is LED or compact florescent and the floor of the library is recycled from tires and tennis shoes. The stairwell of the building is made up of recycled Cyprus tree lumber, the ceiling is bamboo, the floor is ash (fast growing), metal railing in recycled steel, and the carpet is wool. All of these materials are highly sustainable materials. The top of the building is outfitted with a living roof and solar panels which generate 15-20% of energy and is equipped with an advanced geothermal system. Scattered around the building there are 160 wells dug 250 ft in the ground to circulate fluid to heat and cool the building. It is always 55 degrees at that depth which, when the liquid is circulated through, heats or cools the liquid to regulate the building's temperature. The BRIT estimates that the system will obtain a return on investment within 5 years, which is well below the necessary ROI for LEED platinum certification.
It's common knowledge that, up front, sustainability costs money; however, in the end it is very worth it. The living roof alone saves a great deal of money and helps with the heating costs by naturally absorbing the heat from the sun. It has many layers of insulation, gravel, and baskets of soil with native plants. The BRIT worked with biologists from Texas Christian University to create 5,700 native plant baskets which were planted on top of the building.
Our first stop was the pressing room where the guide showed us how the scientists do pressings of botanical collections obtained from all over the world. The collection had presses that were from 1948, 1880, and various other times taken from Texas, Michigan, and even China. Although many of the older pressings only state a general geographic location, the scientists now carry mobile GPS units to pin down the real time location of where specimens are found. Scientists visit herbaria all over the world to benchmark what usually grows naturally in various areas. Next the guide took our group into the library where rolling shelves hold their large specimen collections. They use these rolling shelves to increase the amount of specimens that can be housed in a smaller area. The specimens are organized by family, genus, species, and location of origin. Grad students and other researchers can take samples of plant DNA to do analysis and the BRIT is looking to create a full online collection of high res photos of all 1M+ specimens for students and other collectors can review what is contained in the collection.
They BRIT extends its sustainability efforts to the community by using as little public water and conserving as much run off as possible. To illustrate this, and many of the external conservation efforts, the guide led us on an external tour of the facility. He showed us one of the underground cisterns where rain runoff is housed. The parking lot is sloped exactly to capture the runoff and if the cisterns are full the leftover runoff is naturally led into a private pond. Another great feature of the BRIT is an outside public seating area for events. It is a multi-leved structure where each level is made of a different type of natural rock from Texas. Where we were standing used to be an ocean so those rock represent the layers of rock underneath Fort Worth.
On the outside of the BRIT there are trellises to help increase heat absorption and, to further reduce incoming heat, the building was constructed to face the northeast. While touring the grounds we also noticed that in the parking lot there are "low emission vehicle parking" signs closest to the building. This is to show that the BRIT really appreciates those that strive to protect the environment. The BRIT is also looking into putting in alternative fuel stations around the facility. At the time it was built alternative cars hadn't yet been released so there was no need; however, there is currently a large demand for these fuel stations in the area.
Overall, the tour of the BRIT was very eye opening. I had never seen a LEED platinum building first hand and I was amazed by the level of sustainable materials that were employed. The owner and operator of the research institute were obviously passionate about the success of the building and of the work that they do. I'm excited to learn more about the BRIT's research, especially regarding the work they are doing in the Amazon, and plan to become a member to attend future events. To see more photos of our tour of the BRIT visit my photo page
here.
Q&A with Our Guide
Did the building have to be specially framed due to roof weight and root systems?
- Yes, architects helped build a structure to support the roof and there are root barriers built into the baskets. Oddly enough, in Arizona these roofs are common but not in Texas.
Do you replace dead plants in the living roof?
- Scientific staff actually monitors pop. They monitor what changes over time. What grows due to seeds in soil, blown in by wind, birds, etc. They don't have to replace it because it naturally replaces itself. Also, the scientists are looking at the difference between insects on the grounds and compare them to the insects on the roof.
If something grows on the roof that the BRIT doesn't want, what do you do?
- Johnson grass is infecting the surrounding prairie. It's native to Africa and it's destroying the area. Bermuda grass is doing the same. If necessary they will have to control it in inventive ways.
What is growing in the prairie?
- Mostly 4 or 5 types of tall native grasses.
What type of paper is used to store the specimens in the library?
- Acid free archival paper. Specimens go into a -80 degree freezers to kill insects and prevent any beetles from later infecting the library.
Do you maintain a protected seed bank?
- We don't. We have seeds and some specimens have them archived. We collaborate with long term seed storage but we don't do it.
When specimens are obtained (especially Internationally) do you have issues getting them into the US?
- Yes, you always have to have USDA permission to bring specimens into the US in order to keep out pests and diseases. BRIT has a project in New Guinea and Peru so we have to do that quite often.
Do you do genetic conservation of species?
- No, not particularly. You can find them here though. Scientists often ignore common things and focus on the interesting things. Problem is, without paying attention to the common species we don't really know what has changed in those locations over time. No one is going to come in here and catalog another bluebonnet. But we know we should really be looking at that. We now see things growing in Kansas that scientists know used to only grow in Texas. There is climate change, definitely. We need to track better indicator plants.
Last summer with the hail storm, how did it effect the living roof?
- The plants in North Texas have survived hail storms forever. It didn't damage the roof due to the plants and plants are so tough that they dealt with it just fine.
Do you have special air filtration systems?
- The air is filtered. Not medical or sterile grade but particulates are taken out of the air. It is high enough quality to meet LEED platinum standards which is different depending on the type of building. Plus the building was constructed with materials that make it much easier to have much higher air quality naturally.
Does the ivy growing on the outside of the building eat through the walls?
- These species were selected specifically because they wouldn't do that.
Do you have to mow the roof?
- We actually get that question alot! Ideally you would bring in Bison to do that but no, we don't mow it. We are really waiting for it to get that high and looking for alternative solutions to keep the plants at the best height.
Why is the prairie having trouble growing?
- There was a building on top of that location (the Public Health Center) so it is basically sterile. The scientists are looking for ways to restore the microorganisms and help grow the plants.
